Xe nâng điện đứng lái: nâng hạ và di chuyển hàng hoàn toàn bằng điện
Xe nâng điện ngày một đa dạng về mẫu mã, cũng như là tải trọng và độ cao nâng của xe khi nâng
Type sheet for industrial truck acc.to VID 2198 1KG=2.2LB 1INCH=25.4MM |
Distinguishing
mark |
1.2 |
Manufacturer`s type designation |
|
PS 15 |
1.3 |
Power (battery ,diesel, petrol, gas, manual) |
|
Battery |
1.4 |
Operator type |
|
Pedestrian |
1.5 |
Load Capacity / rated load |
Q (t) |
1.5 |
1.6 |
Load centre distance |
C (mm) |
600 |
1.8 |
Load distance ,centre of drive axle to fork |
X (mm) |
765 |
1.9 |
Wheelbase |
Y(mm) |
1519 |
Weight |
2.1 |
Service weight |
kg |
1596 |
2.2 |
Axle loading, laden front/rear |
kg |
1345/1663 |
2.3 |
Axle loading, unladen front/rear |
kg |
955/553 |
Tyres, chassis |
3.1 |
Tires |
|
Polyurethane (PU) |
3.2 |
Tire size, front |
Ø x w (mm) |
Ø230×75 |
3.3 |
Tire size, rear |
Ø x w (mm) |
Ø 80× 70 |
3.4 |
Additional wheels(dimensions) |
Ø x w (mm) |
Ø124x60 |
3.5 |
Wheels, number front/rear(x=driven wheels) |
|
1x+2/4 |
3.6 |
Tread, front |
b10 (mm) |
750 |
3.7 |
Tread, rear |
b11 (mm) |
390 |
Dimensions |
4.2 |
Lowered mast height |
h1 (mm) |
2220 |
4.3 |
Free lift height |
h2 (mm) |
1660 |
4.4 |
Lift |
h3 (mm) |
4915 |
4.5 |
Extended mast height |
h4 (mm) |
5520 |
4.9 |
Height of tiller in drive position min./ max. |
h14 (mm) |
1370/945 |
4.15 |
Height, lowered |
h13 (mm) |
85 |
4.19 |
Overall length |
l1 (mm) |
2180 |
4.2 |
Length to face of forks |
l2 (mm) |
1030 |
4.21 |
Overall width |
b1 (mm) |
1000 |
4.22 |
Fork dimensions |
s/e/l (mm) |
60/180/1150 |
4.25 |
Distance between fork- arms |
b5 (mm) |
570 |
4.32 |
Ground clearance, centre of wheelbase |
m2 (mm) |
25 |
4.33 |
Aisle width for pallets 1000X1200 lengthways |
Ast (mm) |
2645 |
4.34 |
Aisle width for pallets 800X1200 lengthways |
Ast (mm) |
2592 |
4.35 |
Turning radius |
Wa (mm) |
1806 |
Performance data |
5.1 |
Travel speed, laden/unladen |
Km/h |
6.0/6.0 |
5.2 |
Lift speed, laden/ unladen |
m/s |
0.141/0.212 |
5.3 |
Lowering speed, laden/ unladen |
m/s |
0.227/0.178 |
5.8 |
Max. gradeability performance, laden/ unladen |
% |
41802 |
5.1 |
Service brake |
|
Electromagnetic |
Electric- engine |
6.1 |
Drive motor rating S2 60min |
kW |
1.3 |
6.2 |
Lift motor rating at S3 15% |
kW |
3 |
6.3 |
Battery acc. to DIN 43531/35/36 A, B, C, no |
|
B,3PzS |
6.4 |
Battery voltage, nominal capacity K5 |
V/Ah |
24/ 350 |
6.5 |
Battery weight |
kg |
288 |
6.6 |
Energy consumption acc. to VDI cycle |
kWh/h |
2.1 |
Additional data |
8.1 |
Type of drive control |
|
AC- Speed Control |
8.4 |
Sound level at driver's ear according to EN 12053 |
dB(A) |
70 |
|
